SCS JV

Fast Facts

• A comprehensive 3D BIM approach involved contractors earlier in the HS2 high-speed rail network project.
• Bentley technology facilitated a structured digital
  data approach that will serve as a blueprint for future
  railway projects.

ROI

• A connected data environment streamlined workflows and allowed for early detection of errors to save GBP 1 million.
• Bentley’s integrated BIM applications facilitated data extraction for accurate material quantities and cost estimates, reducing waste.
• Leveraging iModel technology shortened design review time by 20%, saving GBP 500,000.

PT. Waskita

Fast Facts

• The Manggarai Station in Jakarta will replace the
  Gambir Station as the terminus for the city’s long-distance trains in late 2021.
• Waskita was tasked with constructing a new bridge and track slabs, connecting new and existing lines at the station.
• Their success was based on quality, cost, and time efficiency, and required precise decision-making.

ROI

• Using OpenBridge Designer, OpenRail Designer and ContextCapture, Waskita identified and resolved potential issues prior to construction, saving 0.3% per month.
• OpenBridge Modeler’s geometry control functions facilitated accurate calculations for the concrete bridge segments, reducing risks and avoiding unnecessary costs and delays.
• SYNCHRO 4D helped visualize the construction scheme
  and optimize available resources to shorten the
  construction schedule.

SMRT

Fast Facts

• SMRT operates and maintains over 140 kilometers of rail track in Singapore.
• SMRT wanted to upgrade their inefficient processes and improve their maintenance strategy so that the tracks stayed in a good serviceable state.
• SMRT used Bentley’s AssetWise Linear Analytics as the basis of their predictive decision support system.

ROI

• As of August 2019, SMRT achieved 1 million MKBF across all our rail lines.
• With prioritization implementation, they managed to cut down hundreds of manual planning hours and save about 20 maintenance train deployments annually.
• Moving forward, SMRT plans to continuously improve their maintenance efficiency and effectiveness

Sweco NL

Fast Facts

• Sweco NL advanced BIM processes through a connected data environment to digitally manage and share information among 18 disciplines across five countries.
• Sweco NL’s pilot of iTwin Design Review linked digital information from Bentley and third-party applications to enable a digital twins approach.
• Sweco NL leveraged OpenRail Designer and OpenBuildings Designer to realize significant productivity gains.

ROI

• Bentley applications helped reduce design time by 15%.
• Digital twins helped track and manage change reducing construction errors by 25%.
• Sweco NL expects iTwin Design Review to save EUR 1.5 million annually on projects of similar size.

MRT Corp

Fast Facts

• The SSP line will improve transportation in Kuala Lumpur and the Klang Valley region of Malaysia.
• MRT Corp monitors and coordinates more than 20 disciplines during design and construction of the line.
• MRT Corp’s OpenRail CDE facilitates design collaboration, improves construction feasibility, and delivers accurate as-built information.
• MRT Corp’s implementation of digital BIM workflows is driving innovation and BIM adoption throughout the Malaysian construction industry.

ROI

• MRT Corp’s OpenRail CDE enabled seamless sharing of accurate information in real time increasing productivity
  by 35 percent.
• Bentley software enables the integration of design and asset information with MRT Corp’s CMMS to ensure optimal asset lifecycle performance.
• Bentley software enables early validation of asset data and improved accuracy of tag registration to avoid late changes.

Network Rail and Jacobs

Fast Facts

• When completed, the 100-kilometer route upgrade will
  improve connectivity and provide economic benefits
  to the North of England.
• To avoid unnecessary risk and inefficiency Jacobs used Bentley’s iTwin platform and other integrated applications.
• Bringing together the large volume of data and disciplines involved, Network Rail tasked Jacobs with implementing a route-wide digital twin.

ROI

• Using the digital twin meant over 1,300 staff could track, contribute, and analyze design data and asset information in real time.
• Improved access to data saved the team 20,000 hours in the first six months, worth an estimated GBP 1 million.
• Overall, the digital twin is projected to save approximately GBP 15 million.
